| Rated capacities(Emax) | 0.25, 0.3, 0.5, 0.75, 1, 1.5, 2, 2.5, 3, 5, 10 t |
| Sensitivity | 3.0± 0.003mV/V(0.5~10t) 2.0 ± 0.002mV/V(0.25~0.3t) |
| Accuracy class | OIML C2 ~ C5 |
| Creep error (30min) | ± 0.02%F.S. |
| Zero balance | ± 1% F.S. |
| TCO (Temperature Coefficient of Offset) | ± 0.02%F.S. /10°C |
| TC SPAN (Temperature Coefficient of Span) | ± 0.02%F.S. /10°C |
| Input impedance | 400 ± 20 Ω |
| Output impedance | 352 ± 3 Ω |
| Insulation impedance | ≥5000 MΩ (50V DC) |
| Temperature range, compensated | -10°C ~ +40°C |
| Temperature range, operating | -30°C ~ +70°C |
| Maximum safe overload | 150% F.S. |
| Ultimate overload | 180% F.F. |
| Excitation, recommend | 10V ~ 12V DC |
| Excitation maximum | 15V DC |
| Protection class | IP67(0.25~0.75t), IP68(1~10t) |
| Construction | Alloy Steel or Stainless Steel |
| Cable diameter | ⌀5mm(0.25~5t), ⌀6mm(7.5~10t), 4 core |
| Cable Length | 3m(0.25~2.5t), 4.2m(3~5t), 5m(7.5~10t) |
| |
